| Form Factor | SFP | Max Data Rate | 155Mbps |
|---|---|---|---|
| Wavelength | 1550nm-TX/1310nm-RX | Max Cable Distance | 80km |
| Connector | Simplex LC | Media | SMF |
| Transmitter Type | FP | Receiver Type | PIN |
| TX Power | -5 ~ 2dBm | Receiver Sensitivity | < -32dBm |
| DDM/DOM | Supported | Protocols | SFP MSA and SFF-8472 |
| Temperature Range | 0 to 70°C / -40 to 85°C | Warranty | 5 Years |
Drawing on over 10 years of expertise in chips and modules, we integrate fast speeds, compact sizing, power efficiency, and superior performance into every module. We provide a comprehensive range of optical modules tailored for:
Our solutions cater to fixed access, wireless networks, carrier Ethernet, wavelength division multiplexing (WDM), and high-scale data communication networks.
| Part Number | Data Rate | Wavelength | Distance | Components | DDM |
|---|---|---|---|---|---|
| LS-BL315501-10C | 155Mbps | 1310nm-TX/1550nm-RX | 10km | FP/PIN | Yes |
| LS-BL553101-10C | 155Mbps | 1550nm-TX/1310nm-RX | 10km | FP/PIN | Yes |
| LS-BL315501-40C | 155Mbps | 1310nm-TX/1550nm-RX | 40km | FP/PIN | Yes |
| LS-BL553101-40C | 155Mbps | 1550nm-TX/1310nm-RX | 40km | FP/PIN | Yes |
| LS-BL315501-80C | 155Mbps | 1310nm-TX/1550nm-RX | 80km | FP/PIN | Yes |
| LS-BL553101-80C | 155Mbps | 1550nm-TX/1310nm-RX | 80km | FP/PIN | Yes |
End-to-end DWDM solutions including active modules and passive devices like optical amplifiers (EDFA & RFA), Mux & Demux, ROADM, and OTDR.
High-speed optical interconnects ranging from 10G to 800G, designed to handle massive data transmission demands in modern data centers.
High-reliability solutions for 4G/5G systems including Dark Fiber, WDM, and Radio over Fiber for Mid-haul and Back-haul scenarios.
Total fiber access solutions and optical line protection systems (OLP) to ensure network stability and efficient monitoring.
We are a specialized manufacturer certified by ISO9001, RoHS, REACH, CE, and UL. Utilizing advanced manufacturing and testing equipment, we maintain a production capacity of 3000K units per month, ensuring short lead times and top-tier reliability.
